Ease of Operation
With a long working distance of 105mm & smooth Objective changeover from 2X to 4X in Model MS 24 & 1X to 3X in Model MS 13, it provides a stable design for ease of operation.
Parfocal Optics
This allows an erect image of the observed specimen to stay in focus through repeated change in magnification.
![features_image2](https://www.magnusopto.com/pub/media/catalog/product/n/e/new_project_6__5.jpg)
![features_image3](https://www.magnusopto.com/pub/media/catalog/product/n/e/new_project_6__5.jpg)
Options for reflected and transmitted illumination
6v 15w halogen top lamp / LED
5w fluorescent bottom lamp / LED
Items | Model MS 13 | Model MS 24 |
---|---|---|
Microscope Body | -- | -- |
Objective | 1x /3x | 2x /4x |
Working distance | 105 mm | 105 mm |
Diopter Adjustment | plus / minus 5 diopter | plus / minus 5 diopter |
Eye Piece | High eyepoint super widefield SWH 10x with field number 23 | -- |
Field of view | -- | -- |
Objective | 1x 3x |
2x 4x |
Visual Field (mm) | 23 7.7 |
11.5 5.7 |
Light Source | -- | -- |
-- | Reflected | Transmitted |
-- | 6V 15W lamp with adjustable brightness | 5 W fluorescent lamp |
Optional Accesspries | -- | -- |
-- | Fluoresent ring light | Fluoresent ring light |
