Digital Pad

Sensor & Size (mm)

1080P/Sony IMX290, 1/2.8" ( 5.57 X 4.13)

Pixel (um)

2.9 X2.9

Image Capture

2M (1920X1080) with JPEG Format un SD Card

Video Record

1080P 26 fps with AVI Format in SD Card

Camera Control Panel

Including Exposure Gain, White Balance, Color Adjustment , Sharpness Control

Camera Lens Mount



60@1920/1080P (HDMI) , 26 @1920 X 1080(USB)

White Balance

Auto White Balance, Manual White Balance, ROI White Balance

Color Technique

Ultra-Fine TM Color Engine ( USB2.0)

Capture / Control API

Standard UVC for Windows/Linux/Mac (USB2.0)

Recording System

Still Picture or Video (HDMI or USB)

Operating System

Microsoft Window XP/Vista/7/8/8.1/10 (32 & 64 bit), OSx ( Mac OS X), Linux

PC requirment

CPU: Equal to intel Core2 2.8 GHz or Higher, Memory: 4GB or More, USB Port: USB2.0 High Speed Port, CD-ROM

Power Supply

DC 12V/1A Adapter

LCD Panel

IPS LCD Screen ( Super TFT)


281(L)*179(H)*15.6(W) mm

Active Display Area

258mm(W) x 145mm(H)

Pixel Pitch

0.134 (W) x 0.134(H) mm

Input Video Format


Screen Backlight

LED Backlight, 50000 hours


16.7 Millions

Display Type

16:9 Ratio 11.6 Inch Active Matrix Super TFT LCD

Typical Contrast Ratio


Video Format


View Angle

IPS Full View

Screen Brightness

350 cd/sq.m ; 400 cdsq.m/optional

Power Consumption

Max 12W
